The midship double bottoms for HMS Formidable have been transferred into the purpose built Venturer Building at Rosyth, a big step in the assembly of the Royal Navy’s third Type 31 frigate.
The move involved 56 axles of self propelled modular transporters carrying a total of 224 tyres, shifting more than 800 tonnes of steel with careful precision.
The operation, managed by Babcock International, is part of the phased build strategy that sees large prefabricated modules of the ship brought together under cover for integration.
HMS Formidable is the third of five Type 31 general purpose frigates being built for the Royal Navy under a £1.25 billion contract. Designed around the Arrowhead 140 platform, the class is intended to provide a versatile, exportable capability for tasks including maritime security, escort duties, and global forward presence.
Each 5,700 tonne ship will be fitted with the Thales TACTICOS combat management system, Sea Ceptor surface to air missiles, a 57mm main gun, and two 40mm Bofors guns. The frigates will also embark a Wildcat or Merlin helicopter and can deploy unmanned surface and underwater vehicles via a flexible mission bay.
The Type 31 programme is one of the UK’s most significant naval construction efforts, supporting thousands of jobs across the supply chain and forming part of the wider National Shipbuilding Strategy. HMS Venturer, the first of the class, is already in advanced assembly, with HMS Active following closely behind.
HMS Formidable’s move inside the Venturer Building is the beginning of her next build phase, as blocks are aligned, joined, and outfitted ahead of consolidation into the full hull. Once complete, the Type 31s will provide the Royal Navy with a globally deployable, cost effective frigate designed for endurance, adaptability, and sustained operations alongside allies.
