The Defence Science and Technology Laboratory (Dstl) – along with its Defence industry partners MBDA, Leonardo and Qinetiq – is publishing ‘never seen before’ declassified footage of the DragonFire Laser Directed Energy Weapon (LDEW) system, in action over the skies of the Hebrides.
Included is an animated video showing a sample scenario of DragonFire’s possible use in a maritime environment.
The DragonFire Laser Directed Energy Weapon (LDEW) system has proven itself in testing and has the very real potential for it to transform the UK’s Defence capability. Demonstrating the potential of LDEW, DragonFire can provide a credible sovereign UK capability to meet the UK defence needs. LDEW offers a number of significant benefits, including reduced logistic, cost burden and collateral damage in operations.
Animation shows a carrier group consisting of various Royal Navy ships and a Type 26 frigate fitted with DragonFire laser weapon systems (port and starboard), demonstrating a potential layered defence scenario against three threat types. pic.twitter.com/yZt0jOlHE3
— UK Defence Journal (@UKDefJournal) March 11, 2024
What’s in the animation?
A fictitious carrier group consisting of various Royal Navy Ships including a Queen Elizabeth class aircraft carrier and a Type 26 frigate fitted with integrated DragonFire systems (port and starboard) and demonstrating a potential layered defence scenario against three threat types.
The carrier group detects a set of incoming threats via radar (generically: air search mode and marine search mode).
Initially four sub-sonic uncrewed aerial vehicles (UAVs) targets are detected, quickly followed by a super-sonic fast jet target via radar air search. In radar marine (small) target search, a close-in target is picked up (FIAC – Fast Incoming Attack Craft).
This is a hypothetical scenario only. Before engaging any threat, a series of steps are undertaken to establish the nature of the threat and the appropriate response before deciding to engage.
Also, note the Chemring CENTURION trainable decoy launcher to the left of the Dragonfire mount on the Type 26, the two box structures aft of the amidship mushroom farm. Does anyone know what those box structures are, could have sworn I’ve seen them somewhere before.
Beehives.
They already have the beekeepers outfits Frank, so that saves a few bob…..
The box structures are loop antennas for close range but over the horizon communications. The T45s have a similar system.
Its clear this type of weapon will be useful in a maritime environment but it will have limitations as mist, fog and sea spray could limit its effectiveness, getting it airborne in the martime space as well on the surface would help mitigate these limitations. Although it interesting they don’t consider fitting it to the carriers themselves as the bigger = more stable platform, and laser weapons need stabilty to keep the energy focused on one part on the threat long enough to damage it.
Seperately its good to see the T23 with Sea Ceptor performing well in the Red Sea and the Iver Huitfeldt also getting in on the action. Gives us some confidence the T26 and T31 will also perform well in the same scenario.
The laser’s power output has never been a problem. Though to fair you really need over 250kW output to take-out small targets near the horizon or heavily shielded targets closer in. As the higher spot intensity means that it takes less time to burn through the target’s skin. Plus with the higher power you can compensate for some of the dispersion and attenuation effects from the atmosphere.
It is and has always been the ability to keep the laser focused and fixed to a particular point on the target that’s been the problem for these types of weapons. Particularly keeping the beam focused on a moving target. From what I have heard/read, MBDA/Leonardo/Qinetiq have now solved a lot of these issues for Dragonfire. Which means in theory that Dragonfire’s power output could be increased from its published 50kW
Indeed glad you explained that as you get people saying it’s only 50kW but firstly the most important problem to solve is as you say is tracking, ie maintaining spot intensity on a given target which will dictate the power required in the beam itself. Secondly having solved that issue upgrading that overall power while not negligible is by far the more straightforward process.
Overall effectiveness will also be dictated by the target’s form and structure and its sensing and targeting technology. This is where the layered defence comes in as lasers will be extremely effective against many targets and far less so against others. And of course over time there will be adaptations on both sides to improve capabilities to counter the other.
