The first blocks of HMS Active, the second Type 31 Frigate, have been laid out beside HMS Venturer at the Rosyth ‘frigate factory’, showcasing the scale and potential of one of two planned frigate fabrication facilities in Scotland.

At 147 metres long, the hall can comfortably fit three Olympic-sized swimming pools, and the 30-metre high doors can accommodate two vessels being assembled at the same time side by side, just as we’re now seeing.

Construction of HMS Active began with a steel-cutting ceremony at Rosyth in January 2023.

In May 2021, the First Sea Lord announced the names of the five planned Type 31 ships. The names were selected to represent key themes that represent the future plans of the Royal Navy and Royal Marines – forward deployment of ships overseas; operating in the North Atlantic; carrier operations; technology and innovation; and the Future Commando Force.

Active, named after the Type 21 frigate which served in the Falklands War, symbolises forward deployment of ships overseas.

The plan for the Type 31 project envisages all five units of the class being in service by February 2030.

What about the west coast?

With the east coast frigate factory already being utilised, it’s a good idea to look at the progress of the ‘frigate factory’ being built on the west coast for the Type 26 Frigates.

Drone shots show massive Glasgow frigate factory progress

Recent drone imagery shows the progress of a massive new ‘frigate factory’ in Glasgow. The massive facility at Govan represents a huge boost in capability for UK naval shipbuilding, like the ‘Venturer’ building, this facility will be able to build two frigates side by side.
