Qinetiq have discussed the schedule for the testing of ‘Dragonfire’ a new British laser directed energy weapon.

The first project to be undertaken at the new Dragonworks laser test facility will be the assembly and testing of the laser directed energy weapon (LDEW) currently in development by the UK’s Dragonfire consortium.

Components arrived in early 2018 and QinetiQ will started building the weapon’s laser source in the purpose-built clean room. Over the following months, the laser source will undergo a process of evaluation and adjustment before being integrated with Leonardo’s beam director.

The project will culminate in operation at full-power under test conditions inside the facility “soon”, before it is transported to MOD Shoeburyness for long-range outdoor trials later in the year.

How the system would work.

Data collected using the Reflective Hazard Assessment Tool will inform the safety case for these and future trials, ensuring the reflectivity of targets is fully understood and any risk mitigated accordingly.

Peter Cooper, the Project Technical Authority in Dstl, which manages the Dragonfire contract on behalf of the UK MOD, said regarding the new test facility:

“This facility is a key step in delivering the Dragonfire project and reflects the continuing UK MOD investment, supported and enabled by industry funding, amounting to tens of millions of pounds in UK industrial skills and capabilities and underpinning UK prosperity.”
