The Ministry of Defence has published a preliminary market engagement notice under Project VANQUISH, seeking industry views on a new “Fixed Wing Short Take Off and Landing Autonomous Collaborative Platform” (FW STOL ACP) for Royal Navy carriers.
The Find a Tender listing describes the effort as a technical demonstration intended to inform future procurement options for the UK’s “Hybrid Air Wing”.
The notice, identifier 2025/S 000-062294, sets out the requirement in stark terms: “Project VANQUISH seeks to deliver a technical demonstration at sea of an attritable (Tier 2) Fixed Wing Short Take Off and Landing Autonomous Collaborative Platform (FW STOL ACP); nominal target date by the end of 2026, with options for delivery within an 18 month window from the target date also considered.”
The MOD is explicit that the platform must be able to embark and operate autonomously from a Queen Elizabeth-class aircraft carrier. It is to be jet turbine powered, capable of high subsonic speed, and launch and recover from carriers without catapults or arrested recovery systems.
The system is expected to carry a credible payload with sufficient endurance, with a clear exploitation path for roles such as ISR, strike, and air-to-air refuelling.
The RFI highlights that this effort should “complement F-35B Lightning, as part of QEC and its Carrier Air Wing”. Officials also stress that the work must be “aligned with the principles of Maritime Aviation Transformation (MATX) and build on previous trials and demonstrations of ACPs from QEC.”
The estimated contract value is £10 million excluding VAT (£12 million including VAT), with a potential period from April 2026 to December 2027. The MOD notes that successful completion will provide the data and evidence needed to support a prospective procurement of a carrier-capable autonomous strike aircraft in the early 2030s.
The notice makes clear this is not yet a formal procurement. “For the avoidance of doubt, this notice is not informing the market of an imminent procurement. All costs pertaining to the completion of this response are to be borne by the responders.” A formal tender is expected to follow in January 2026.
Industry is invited to respond by 14 November 2025 through an online submission form. Clarification questions must be submitted by 24 October.
