Footage from the terminal phase of the first in-service night firing of Martlet has been published by 815 Naval Air Squdron

The video was recorded on an exercise on a Danish range and is the first in-service night firing from an aircraft.

Msrtlet is a lightweight, precision strike multirole missile designed to be fired from a variety of tactical platforms on Land, Sea and Air against a wide range of conventional and asymmetric threats.

The target set includes surface threats such as static installations, Armoured Personnel Carriers (APC), asymmetric threats, fast in-shore attack craft and UAVs.

Up to 20 missiles can be loaded onto a Wildcat HMA Mk2 helicopter. In 0.3 seconds, the missile detaches from the helicopter, accelerating to one and a half times the speed of sound towards its target.

Avatar photo
George has a degree in Cyber Security from Glasgow Caledonian University and has a keen interest in naval and cyber security matters and has appeared on national radio and television to discuss current events. George is on Twitter at @geoallison
