The composite mast for second Type 26 Frigate HMS Cardiff has arrived in Glasgow from specialist supplier Umoe Mandal in Norway.

Below you can see images of the mast taken this morning.

In 2020, Umoe Mandal was awarded a contract for three shipsets of composite mast and SCOT Sponsons structures for the Royal Navy’s first batch of Type 26 Frigates, designed and manufactured by BAE Systems.

Recently, work started to prepare HMS Glasgow for being moved onto a barge ahead of float-off.

New drone images show new frigate HMS Glasgow before launch

The Type 26 represents the future backbone of the Royal Navy and eight of the class are planned, starting with HMS Glasgow. The eight ships will replace the eight dedicated anti-submarine Type 23 frigates which will reach the end of their active lives by the mid 2030s.

In addition to the Clyde built Type 26, five Rosyth built Type 31 general purpose frigates are intended to replace the general-purpose Type 23s currently in service and also coming towards the end of their long careers.
