Exclusive drone footage reveals the rapid development of the new shipbuilding hall at BAE Systems’ shipyard in Govan, Glasgow.

The Janet Harvey Hall wil significantly enhance the UK’s naval shipbuilding capabilities.

The massive facility’s construction involves over 6,000 tonnes of steel and 20,000 cubic metres of concrete. Once completed, it will accommodate two Type 26 Frigates side by side, providing a substantial boost in production efficiency.

Glasgow frigate factory named Janet Harvey Hall by BAE

The footage, captured legally by a qualified drone operator in compliance with UK drone legislation, offers a detailed look at the scale and progress of the build. The operator ensured all safety measures, including insurance and a pre-approved flight plan, were in place.

Previously, the assembly of HMS Glasgow took place in an outdoor hard-standing area, where sections built in the existing hall were joined. The new shipbuilding hall will allow for indoor assembly, shielding the process from weather conditions. This modernisation effort aims to increase the yard’s capacity and efficiency.

The new hall, measuring approximately 81 metres wide, 170 metres long, and 49 metres high, will be a significant upgrade while the original build hall remains operational. The facility’s completion is expected to streamline the production of future Type 26 Frigates, reinforcing the UK’s naval infrastructure.

The Type 26 frigate, also known as the City-class frigate, represents the next generation of anti-submarine warfare vessels being developed for the Royal Navy. Variants are planned for the Royal Australian Navy and the Royal Canadian Navy. This project, known as the Global Combat Ship programme, aimed to replace the Royal Navy’s ageing Type 23 frigates and to offer a versatile platform for export.

The Type 26 frigate originated from the Future Surface Combatant (FSC) programme, which began in 1998 to find replacements for the Type 22 and Type 23 frigates. Initial concepts included various designs, such as a trimaran hull, but by 2010, the focus shifted to a more conventional and flexible design under the Global Combat Ship programme, you can find out more about the ship in one of our previous guides to the vessel.
